Double Needle Four Thread Automatic Sewing Machine
Products Description
The double-needle four-thread fully automatic pure bag sewing machine is developed based on the fully automatic bag sewing machine. It can sew two stitches at the same time, effectively preventing material leakage, and the stitch distance and line distance are consistent, which improves work efficiency.
Specifaication
| Item | Double needle four thread automatic sewing machine |
| Maximum sewing speed | 1900 RPM |
| Working speed | 1700 RPM |
| Maximum sewing thickness | 8mm |
| Stitch adjustment range | 6.5-11mm |
| Sewing stitch type | Double wire chain type (401) |
| Needle model | 80800 (200-250#) |
| Thread specification | 20/6, 20/9 synthetic fiber or cotton thread |
| Pulley diameter | φ114mm |
| Thread cutting form | Electro-pneumatic type |
| Motor power | 370W |
| Machine weight | 33kgs |
| Dimensions | 350x240x440 (mm) |
feature
1. High efficiency
Double needle four thread automatic sewing machine uses two needles to sew at the same time, which means that two trips of work can be completed at one time. This design greatly improves the speed and efficiency of sewing and is particularly suitable for occasions that require high production efficiency.
2. Good sewing quality
Due to the use of double needle four thread sewing, the sewn bag seal is more solid and reliable. This sewing method can ensure that the package is leak-free, especially suitable for occasions with strict requirements on the quality of the seam.
3. Wide range of applications
Double-needle four thread bag sewing machine is suitable for many types of bags, such as paper bags, plastic woven bags, and cloth bags. This makes it play a role in different packaging needs.
4. High degree of automation
This type of machine is usually equipped with the function of automatic wire braid cutting, and the photoelectric switch automatically controls the start and stop of the machine, which reduces the need for manual operation and improves the degree of automation.
5. Durability and reliability
The double needle four thread bag sewing machine is designed for a continuous high-intensity working environment, so it performs well in durability and reliability.
6. Lower maintenance cost
Due to their structural design and technical characteristics, these machines usually require less maintenance and the maintenance cost is relatively low.
